ASTM Stainless Capillary Tube Stainless Capillary Tube 12000M Annealed With Ferrule Fittings

Meilong Tube specializes in producing seamless and redrawn, welded and redrawn coiled tubing made from corrosion-resistant austenitic, duplex, super duplex stainless steels and nickel alloy grades. These tubing are often used in hydraulic control lines and chemical injection lines, specifically to serve the oil and gas, and geothermal industries.

The unique manufacturing capabilities and processes of Meilong Tube allow it to make the longest continuous chemical injection line tubing available in stainless steels and high nickel alloys. These long length tubing coils are often used for chemical injection in subsea and onshore wells. Their length aids to reduce the potential for defects and failures and their exceedingly clean and smooth inside surface is perfect for chemical injection systems.

The coils also have short hydraulic response times, great collapse strength, and absolutely no methanol permeation.

The Duplex 2205 is a nitrogen-enhanced duplex stainless steel developed to combat the common corrosion problems caused by the 300 series stainless steels. It contains a combination of austenite and ferrite phases, and at its annealed state, it has around 40-50% ferrite. Also referred to as the work horse grade, the 2205 duplex stainless steel is the most widely used type in its family.

The advantage of duplex steel is that it combines the qualities of austenitic and ferritic steel, making it easy to fabricate with high stress resistances and corrosion resistance. However, its usage should be limited to temperatures below 600° F, as extended exposure to higher temperatures can make it brittle over time.

The chromium, molybdenum, and nitrogen elements offer great resistance to chloride pitting and crevice corrosion, which is essential in services such as marine environments, bleaching operations, brackish water, closed loop systems, and food process applications. Furthermore, the resistance of 2205 duplex stainless steel is incomparable to common stainless steels like SS316L and SS317L.

Features:

Meilong Tube ensures a flawless product quality by providing vacuum annealing for injection lines, allowing for excellent mechanical properties and a bright, appealing surface. In addition, close dimensional tolerances, superior surface finish, high cleanness of the inside surface, and controlled ovality and eccentricity are achieved.

Each tubing coil is a completely continuous length free of orbital welds and is hydrostatically tested at a minimum of 10,000 psi. Tests such as eddy current, chemical, flattening, flaring, tensile, yield, elongation, and hardness are conducted to guarantee quality and reliability. Furthermore, third party inspectors (SGS, BV, DNV) can be present onsite to witness the tests.

Technical Parameters:

We are manufacturing and supplying seamless, floating internal plug redrawn tubing. It is made by seam-welding and therefore free from any orbital joint welds. The tubing is provided in an annealed condition and is supplied in one continuous length. It features some UNS alloy construction.

The specifications include:

Please note that the theoretical burst and collapse pressure values are based on minimum wall thickness and minimum tensile/yield strength respectively. In addition, all the pressure ratings provided are for use in static, neutral, and 100°F (38°C) temperature conditions.

Applications:

Our extensive selection of coiled alloy tubing offer ideal solutions for a variety of needs and applications. For example, our capillary tubing is suitable for chemical injection. In addition, hydraulic control line coiled alloy tubing is offered in both bare and encapsulated form. This makes it a great choice for subsea safety valves. Not to mention, our product range also includes velocity strings, work strings, and steel tube umbilicals. Lastly, our coiled alloy tubing is also used in geothermal applications.

These reliable tubing products are designed and engineered to meet the ever increasing demands of today’s complex deepwater operations. They provide a safe, efficient and cost-effective way of transferring fluids and gases underwater or overland. Our team of experts are on hand to provide technical support and guidance to ensure you get the right solution for your needs.

Our global supply chain further ensures that you get the perfect tubing, delivered exactly when and where you need it. For more information on our coiled alloy tubing solutions, please contact us today.

Customization:

Meilong Tube is proud to present its Stainless Steel Coiled Tubing with an unparalleled range of customization options. Our Stainless Steel Coiled Tubing is made from Duplex 2205, and is available in 3/8''OD x 0.065''WT size. Its use purpose is for hydraulic control and chemical injection, and is ideal for use in oil and gas industry, for down hole application. Each coil is 100% length hydrostatic tested to ensure quality. We offer ASTM A789 Standard with a minimum order quantity of 1 coil, and a maximum supply capacity of 150 metric tons per month. Our Stainless Steel Coiled Tubing is certified with ISO9001 and is safely packaged in wooden cases. We accept payment terms of T/T and L/C and delivery within 7 days.

Support and Services:

Stainless Steel Coiled Tubing technical support and services include:

• Provide technical guidance on application and installation
• Provide product customization services
• Provide after-sales service and maintenance
• Provide technical consultation and training
