Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing

Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing
Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing

Large Image :  Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing

Product Details:
Place of Origin: China
Brand Name: Meilong Tube
Certification: ISO9001
Model Number: 1/4''OD x 0.065''WT
Payment & Shipping Terms:
Minimum Order Quantity: 1 coil
Packaging Details: Wooden case
Delivery Time: In 7 days
Payment Terms: T/T, L/C
Supply Ability: 150 metric tons per month

Annealed Stainless Steel Coiled Tubing Gas Sector High Pressure Capillary Tubing

Description
Feature: High Tensile Strength And Elongation NDT: 100% Length Is Eddy Current Tested
Size: Close Dimensional Tolerance Application: Down Hole Application In Oil And Gas Industry
Use Purpose: Hydraulic Control And Chemical Injection Pressure Test: 100% Length Is Hydrostatic Tested
Connection Type: Ferrule Fittings Length: Up To 12000 Meters
High Light:

Annealed Stainless Steel Coiled Tubing

,

SS316 Stainless Steel Coiled Tubing

,

Gas Sector high pressure capillary tubing

Annealed Capillary Stainless Steel Coiled Tubing 100% Length Eddy Current Tested Highly Clean & Bright Surface

Product Description:

Meilong Tube's Corrosion Resistant Tubing Products For Oil & Gas Sector

Meilong Tube offers tubing products for the oil & gas sector, that have been successfully applied to some of the most extreme conditions, underwater and deep in the Earth's surface. The products have consistently passed the strict quality requirements of this sector over the years.

Their vast selection of corrosion-resistant products come in stainless steels, nickel alloys, and TP316L Austenitic Chromium-Nickel stainless steel with molybdenum and low carbon content.

The usability and durability of Meilong Tube's products hold up against organic acids at high concentrations and moderate temperatures, including acid like phosphoric and sulphuric acid, as well as salt solutions, and caustic environments.

However, Austenitic steels are still susceptible to stress corrosion cracking, so it's advised that service conditions over 60°C (140°F) be avoided. Plants that are shut down, especially when condensates form can lead to both stress corrosion cracking and pitting, potentially damaging Meilong Tube's product if not monitored.

TP316L is known for its resistance to intergranular corrosion, being a low carbon content steel. This ensures the products stay durable in their meant-for surroundings.



Features:

Precision Manufacturing

Meilong Tube operates from a complex of buildings totaling 20,000 square meters.

The company has multiple tube mills designed and fabricated by Meilong Tube for forming and gas-tungsten arc and laser beam welding from strip stock.

For certain tubing dimensions, Meilong Tube employs two different processes. Sinking, a cold working process in which tubing is pulled through a lubricated dies without an internal plug, and floating-plug operation, a cold working process in which tubing is pulled through a lubricated die with an internal floating plug which controls inside diameter of tubing.

The tubing is heat-treated to achieve specified mechanical properties and corrosion resistance in an off-mill furnace with a reducing atmosphere.



Technical Parameters:



Applications:

Down Hole & Umbilical Tubing:
Meilong Tube’s long length alloy tubing in coils are used extensively for chemical injection and hydraulic control in subsea and onshore wells. The long length is continuous without orbital welds which reduces the potential for weld-related defects and failures. Additionally, our tubing coils have an extremely clean and smooth ID surface that is ideal for hydraulic and chemical injection systems. Tube coils offer short hydraulic response time, greater collapse strength, and elimination of methanol permeation.

Applications include:

  • Hydraulic power
  • Single transmission
  • Monitoring and control equipment
  • Chemical injection lines
  • Downhole safety valve control
  • Subsea safety valve control
  • Umbilical control lines
  • Topside instrumentation and impulse lines
  • Wellhead control panel
  • Downhole gauge cable





Customization:

Stainless Steel Coiled Tubing

Brand Name: Meilong Tube
Model Number: 1/4''OD x 0.065''WT
Place of Origin: China
Certification: ISO9001
Minimum Order Quantity: 1 coil
Packaging Details: Wooden case
Delivery Time: In 7 days
Payment Terms: T/T, L/C
Supply Ability: 150 metric tons per month

Features:

  • Size: Close Dimensional Tolerance
  • Working pressure: Above 10000 Psi
  • NDT: 100% Length Is Eddy Current Tested
  • Length: Up To 12000 Meters
  • Condition: Annealed

Specialty: Stainless steel coiled capillary tubing, Stainless steel coiled tubing injection line, Duplex 2205 stainless steel coiled tubing.



Support and Services:

Technical Support and Service for Stainless Steel Coiled Tubing

We provide comprehensive technical support and service for our stainless steel coiled tubing. Our team of experienced and knowledgeable professionals are available to help you with selecting the right tubing for your application, answer any questions you have about our products, and provide design and installation advice.

We offer a wide variety of services including:

  • Product selection and specification
  • Fabrication and installation services
  • Inspection and testing services
  • Product maintenance and repair
  • On-site support and troubleshooting

Our team is available 24/7 to answer any questions you have and provide the technical support you need to get the job done right.
