Ferrule Fittings Stainless Steel Coiled Tubing Hydraulic Control Line High Tensile Strength Elongation 100% Length Hydro
Product Description:
Meilong Tube offers coiled tubing in a wide range of corrosion resistant stainless steels, nickel alloys, with extensive experience in product supply and innovation in oil & gas sector. Among them, TP316L austenitic chromium-nickel stainless steel is especially widely used. It has a low carbon content and therefore better resistance to intergranular corrosion than steels of type TP316. Additionally, TP316L exhibits excellent weldability, with or without the addition of filler metal.
The tubing products for the oil & gas sector have been applied in some of the most aggressive subsea and downhole conditions. Meilong Tube has a long proven track record of supplying products that satisfy the strict quality requirements of the oil and gas sector in terms of corrosion resistance. TP316L shows good corrosion resistance to organic acids at high concentrations and moderate temperatures, inorganic acids like phosphoric and sulphuric acids, salt solutions(e.g. sulphates, sulphides and sulphites), as well as caustic environments. However, attention must be paid to avoid stress corrosion cracking, which may occur at temperatures above about 60°C (140°F) and exposure to certain solutions containing chlorides.
Features:
Meilong Tube operates from a complex of buildings totaling 20,000 square meters. Its tube mill is designed and fabricated by the company itself. Tubing is formed, and gas-tungsten arc and laser beam welded from strip stock on this tube mill.
Sinking is a cold working process in which tubing is pulled through a lubricated die without an internal plug. In some cases, which manufacturing process limitations restrict welding the tubing to final size, the tubing is welded at a larger outside diameter and sunk in multiple reduction / heat treatment operations.
Floating-plug operation is also a cold working process, but in this process tubing is pulled through a lubricate die with an internal floating plug which controls inside diameter of tubing.
The tubing is also heat-treated to achieve specified mechanical properties and corrosion resistance in an off-mill furnace with a reducing atmosphere.
Technical Parameters:
Applications:
.
Customization:
- Brand Name: Meilong Tube
- Model Number: 1/4''OD x 0.065''WT
- Place of Origin: China
- Certification: ISO9001
- Minimum Order Quantity: 1 coil
- Packaging Details: Wooden case
- Delivery Time: In 7 days
- Payment Terms: T/T, L/C
- Supply Ability: 150 metric tons per month
- Working pressure: Above 10000 Psi
- NDT: 100% Length Is Eddy Current Tested
- Pressure Test: 100% Length Is Hydrostatic Tested
- Material: Stainless Steel 316L
- Application: Down Hole Application In Oil And Gas Industry
- Keywords: Stainless steel coiled tubing injection line, Stainless steel coiled tubing chemical injection line, Duplex 2507 stainless steel coiled tubing, stainless steel 316L coiled tubing, stainless steel 304 coiled tubing
Support and Services:
Stainless Steel Coiled Tubing Technical Support and Service
We offer extensive technical support and service for our Stainless Steel Coiled Tubing products. Our team of experts are available to answer any questions you may have, provide product advice, and to help you with your project. We also offer customized solutions and testing services.
If you are looking for help with installation, we provide detailed instructions and tutorial videos to ensure that your Stainless Steel Coiled Tubing is installed correctly. We also provide troubleshooting services in case you experience any issues.
Our commitment to you is to provide the best possible service and technical support for your Stainless Steel Coiled Tubing needs.
