Duplex 2507 Chemical Injection Line 1 2 Stainless Steel Hydraulic Tubing For Down Hole

Super Duplex 2507 SS Hydraulic Tubing for Down Hole Application in Oil and Gas Industry Hydraulic Control and Chemical I

Product Description:

Meilong Tube provides tubing products that prove its capability for the most aggressive subsea and downhole missions in the oil & gas sector. With a long-established track record, we guarantee our products to meet the strict quality standards of the industry. Our coiled tubing is available in a wide variety of corrosion resistant stainless steels, nickel alloys, and other types of alloys, depending on the specific project requirements.

Flow assurance and the accuracy of chemical delivery are vital to effective upstream processes of oil and gas production. For this reason, we manufacture our coils with integrity and quality to be used in the subsea. Our tubing has been applied to umbilicals, creating the most effective chemical storage and delivery systems. We also specialize in hydraulic control line tubing, meeting customer and industry-specific requisites with our expertise in producing coiled tubing out of duplex, nickel alloy and stainless steel grades.

Features:

Meilong Tube operates from a complex of buildings totaling 20,000 square meters.

The industrial tubing is formed and gas-tungsten arc and laser beam welded from strip stock on multiple tube mills designed and fabricated by the company.

In certain situations when manufacturing process limitations prevent welding the tubing of the desired size, it needs to be welded at a larger outside diameter and be sunk in multiple reduction / heat treatment operations. This procedure is called sinking operation and is a cold working process in which tubing is pulled through a lubricated die without an internal plug.

Floating-plug operation is another cold working process in which tubing is pulled through a lubricated die with an internal floating plug that regulates the inside diameter of the tubing.

The tubing is finally heat-treated to make sure it meets the specifications and obtains the desired resistance to corrosion, all in an off-mill furnace with a reducing atmosphere.

Technical Parameters:

Applications:

Down Hole & Umbilical Tubing provided by Meilong Tube is designed for a range of specific applications, such as hydraulic power, single transmission, monitoring and control equipment, and chemical injection lines. It is particularly suited for downhole safety valve control, subsea safety valve control, umbilical control lines, topside instrumentation and impulse lines, wellhead control panel, and downhole gauge cable.

Our tubing coils are designed for long length and without orbital welds, which makes it stand out from those with welds, and reduces the chance of weld-related failure. Additionally, Meilong Tube also ensures all its products have an extremely clean and smooth inner surface, making it ideal for hydraulic and chemical injection systems. Compared to other suppliers, Meilong Tube offers superior advantages such as short hydraulic response time, greater collapse strength, and elimination of methanol permeation.

Customization:

Support and Services:

SS Hydraulic Tubing offers a full range of technical support and services:

• Providing detailed product information and technical specifications.
• A comprehensive installation guide and instructions.
• Timely response to any technical queries.
• A dedicated customer service team.
• Regular maintenance and inspection services.
• Free trial and after-sales support.
