ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube

ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube
ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube

Large Image :  ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube

Product Details:
Place of Origin: China
Brand Name: Meilong Tube
Certification: ISO9001
Model Number: 1/4''OD x 0.065''WT
Payment & Shipping Terms:
Minimum Order Quantity: 1 coil
Packaging Details: Wooden case
Delivery Time: In 7 days
Payment Terms: T/T, L/C
Supply Ability: 150 metric tons per month

ASTM A789 1/8in Hydraulic Control Line Duplex SS Thin Walled Capillary Tube

Description
Material: Duplex Stainless Steel Application: Down Hole Application In Oil And Gas Industry
Pressure Range: Extremely High Pressure Length: Up To 12000 Meters
Standard: ASTM A789 Size: Tight Dimensional Tolerances
Surface: Highly Clean And Bright Feature: High Tensile Strength
High Light:

ASTM A789 Hydraulic Control Line

,

1/8in Hydraulic Control Line

,

Duplex SS thin walled capillary tube

100% Tested ASTM A789 High Yield Hydraulic Control Line Ferrule Fittings

Product Description:

Meilong Tube has been dedicated to bringing a number of technological advancements to the industry, such as raising the maximum length of tubing that can be produced without any orbital welds. In addition, Tube Encapsulated Conductors (TEC) was initially launched in the oil and gas industry by Meilong Tube.

Our management team is composed of skilled experts from the industry, and they share the same commitment to quality management, customer satisfaction, as well as the passion for creating a better experience for our customers. With rich industry knowledge and tens of years’ collective experience in tube manufacturing and customer service, the professionals here strive to make sure our clients get customized pieces that meet their requirements.

Meilong Tube's vision is to always surpass every customer's expectations for quality, convenience, as well as the responsiveness of our team. Your satisfaction is our utmost priority, and it is our honor to serve as your Meilong Tube customer.



Features:

The process of orbital welding, which has been used by some in our industry, is no longer necessary to produce hydraulic Control Lines. Our production of seam-welded tubing uses TIG and laser beam welding machines to ensure high quality, repeatable welds.

Additionally, we have cold-drawing machines in our facility that allow us to produce tubing with OD sizes ranging from 1/8” to 1” and wall thicknesses from 0.028” to 0.095”. The materials that we commonly use are 316L, Duplex 2205, Super Duplex 2507, Incoloy 825, and Inconel 625.



Technical Parameters:

User's Guide of Duplex 2205

Seamless & floating internal plug redrawn tubing supplied in the annealed condition is applicable to alloy UNS S32205. The collaspes pressure, test pressure, working pressure and burst pressure are listed in following table. All the pressures are at 100°F (38°C), neutral and static conditions. The theoretical burst pressure is based on minimum wall thickness and minimum tensile strength. The theoretical collapse pressure is based on minimum wall thickness and minimum yield strength.

Alloy UNS O.D. W.T. Working Pressure Burst Pressure Collapse Pressure Test Pressure
Duplex 2205 S32205 1/8 0.125 0.028 15,544 41,704 15,544 17,400
Duplex 2205 S32205 1/8 0.125 0.035 19,430 52,130 19,430 21,025
Duplex 2205 S32205 1/4 0.250 0.035 9,715 26,065 9,715 10,875
Duplex 2205 S32205 1/4 0.250 0.049 13,631 31,784 12,821 14,500
Duplex 2205 S32205 1/4 0.250 0.065 18,076 40,182 15,824 19,575
Duplex 2205 S32205 3/8 0.375 0.035 6,492 22,226 6,786 7,250
Duplex 2205 S32205 3/8 0.375 0.049 9,082 25,230 9,156 10,150
Duplex 2205 S32205 3/8 0.375 0.065 12,056 29,302 11,629 13,050
Duplex 2205 S32205 3/8 0.375 0.083 15,382 34,858 14,087 16,675
Duplex 2205 S32205 1/2 0.500 0.049 6,815 22,574 7,095 7,250
Duplex 2205 S32205 1/2 0.500 0.065 9,038 25,172 9,126 10,150
Duplex 2205 S32205 1/2 0.500 0.083 11,540 28,536 11,217 13,050
Duplex 2205 S32205 5/8 0.625 0.049 5,446 21,147 5,785 5,800
Duplex 2205 S32205 5/8 0.625 0.065 7,213 23,038 7,492 7,975
Duplex 2205 S32205 5/8 0.625 0.083 9,229 31,216 9,288 10,150
Duplex 2205 S32205 3/4 0.750 0.049 4,534 20,265 4,887 5,075
Duplex 2205 S32205 3/4 0.750 0.065 6,020 21,738 6,344 6,525
Duplex 2205 S32205 3/4 0.750 0.083 7,684 23,560 7,919 8,700


Applications:

Hydraulic Control Line is used in a wide range of commercial and industrial applications, and is made of high quality stainless steel and super duplex steel. Meilong Tube's 316L Hydraulic Control Line and Super Duplex 2507 Hydraulic Control Line offer superior corrosion resistance, superior tensile strength, and superior ductility, making them ideal for use in demanding and critical applications. It is available in 1/4''OD x 0.065''WT and is designed and manufactured in accordance with ASTM A789, and certified by ISO9001. With a minimum order quantity of 1 coil and a supply capacity of up to 150 metric tons per month, customers can enjoy quick delivery and convenient payment terms like T/T, L/C. All lengths are 100% length hydraulic tested and carefully packed in wooden cases. With superior performance, Meilong Tube's Hydraulic Control Line is the perfect choice for any application.


Customization:

Customized Nickel Alloy/Stainless Steel Hydraulic Control Line

Brand Name: Meilong Tube

Model Number: 1/4''OD x 0.065''WT

Place of Origin: China

Certification: ISO9001

Minimum Order Quantity: 1 coil

Packaging Details: Wooden case

Delivery Time: In 7 days

Payment Terms: T/T, L/C

Supply Ability: 150 metric tons per month

Connection Type: Ferrule Fittings

Feature: High Tensile Strength

Length: Up To 12000 Meters

Pressure Range: Extremely High Pressure

Surface: Highly Clean And Bright

Meilong Tube Offers Customized Nickel Alloy/Stainless Steel Hydraulic Control Line Service

Meilong Tube is a professional manufacturer of Nickel Alloy and Stainless Steel Hydraulic Control Line. We specialize in producing Hydraulic Control Line with high tensile strength, extreme pressure resistance, and highly clean and bright surface. Our Hydraulic Control Line can be customized with various specifications, such as 1/4''OD x 0.065''WT, up to 12000 meters in length, and ferrule fittings connection type. The minimum order quantity is 1 coil, and we can provide 150 metric tons per month. Our Hydraulic Control Line is certified with ISO9001 and can be delivered in 7 days. Payment terms accepted are T/T, L/C. All our products are well packaged with wooden cases.



Support and Services:

Hydraulic Control Line Technical Support and Service

We provide reliable and comprehensive Technical Support and Service for our Hydraulic Control Line products. Our experienced and knowledgeable staff is available to assist you with any questions or problems you may have.

Our Technical Support and Service includes:

  • Product installation, maintenance and troubleshooting assistance
  • Software updates and bug fixes
  • Hardware repair and replacement
  • Technical advice and support

We are committed to providing the highest quality Technical Support and Service for our customers. If you have any questions or need assistance, please don’t hesitate to contact us.
